Application Media: R134a, R404a
Application Temp: -40℃ to +135℃
Standard: SAEJ2064
Specification
| NO. | DN | I.D. | O.D. | W.T. | W.D.M. | W.P. | B.P. | Min B.R. |
| mm | mm | mm | mm | mm | MPa | MPa | mm | |
| 1 | 8.0 | 8.4 | 18.7 | 3.50 | 0.4 | 3.5 | 23.0 | 55 |
| 2 | 10.0 | 10.5 | 22.2 | 3.50 | 0.4 | 3.5 | 22.0 | 65 |
| 3 | 11.5 | 11.5 | 18.1 | 3.60 | 0.4 | 3.5 | 21.0 | 70 |
| 4 | 13.0 | 13.2 | 23.0 | 3.80 | 0.4 | 3.5 | 24.0 | 75 |
| 5 | 15.5 | 16.3 | 24.0 | 3.80 | 0.4 | 1.5 | 20.0 | 85 |
| 6 | 19.0 | 18.5 | 27.5 | 4.50 | 0.4 | 1.5 | 12.0 | 100 |
| 7 | 28.5 | 28.5 | 39.7 | 5.50 | 0.5 | 1.5 | 12.0 | 180 |
