The Use and Characteristics of High-Pressure Steel Wire Wound Rubber Hose are Introduced in Detail

Feb. 22, 2023

The Use and Characteristics of High-Pressure Steel Wire Wound Rubber Hose are Introduced in Detail

SANYEFLEX High-pressure steel wire spiral hose is mainly used in mining hydraulic support, oil field mining, construction, lifting and transportation, metallurgical industry forging, mining machinery and equipment, ships, injection, agriculture and animal husbandry, various CNC lathes and various industrial sectors Crude oil with special pressure and humidity in the mechanical automation and fully automatic hydraulic press system, the rubber hose made of stainless steel wire is made according to the design standard of GB/T3683-1992, and ISO/DIS1436-1985, DIN20022, SAE100RIAT, SAE100R2AT can be made according to the needs Specification for plastics, this specification is not suitable for castor oil naphthenic aliphatic liquid.


Function of high pressure steel wire wound rubber hose:


1. The rubber hose is made of unique styrene-butadiene rubber, which has good acid and alkali resistance, high temperature resistance and aging resistance.

2. The plastic hose rolling bearing has high working pressure, and the single pulse is cost-effective.

3. Intense fusion, soft application, small deformation under pressure.

4. It has good compressive strength and fatigue relief.

5. The length of the cable braided hose is 20 meters above 32, and 10 or 100 meters below 25.


High-pressure steel wire wound rubber hose is mainly used to transmit high-temperature, high-pressure gasoline, oil, pepper oil (flammable and explosive substances) from aircraft fuel, mining hydraulic support, oilfield mining, and construction machinery hydraulic systems to transmit pressure.


Product structure: It is mainly composed of liquid-resistant styrene-butadiene rubber inner adhesive, middle rubber layer, I, II, and III stainless steel wire braiding layers, and weather-resistant styrene-butadiene rubber outer adhesive. The inner adhesive has the ability to withstand the transmission of materials , to ensure that the stainless steel wire will not be corroded, the outer viscose protects the stainless steel wire from damage, and the stainless steel wire layer is a skeleton material, which plays a role in improving.


Microstructure of high-pressure steel wire wound rubber hose:


It is mainly composed of inner liquid and inner glue, middle glue layer, 2, 4, and 6 layers of thin iron wire, including reinforcement layer and outer glue. The inner layer can put pressure on the conveying material to ensure that the stainless steel wire will not be corroded. The outer adhesive layer protects the cable from damage, and the cable (0.3-2.0 reinforced cable) layer is a reinforced skeleton.


Styrene-butadiene rubber should be made of nitrile rubber with better wear resistance, coupled with a unique synergist, as the inner plastic layer, closely bonded, soft in application, small in force deformation, and has bending resistance and wear resistance sex. The outer plastic layer is made of special styrene-butadiene rubber, which is a fiber material with a higher density than ordinary plastics, so it has wear resistance.


High-pressure steel wire spiral hose is mainly used in mining hydraulic supports and oil field mining, suitable for construction, lifting and transportation, metallurgical industry forging, mining machinery, ships, injection molding processing machinery, agricultural machinery, various CNC lathes and various Mechanical automation and automation technology hydraulic press systems in various industrial sectors transport petroleum-based liquids (such as mineral oils, aromatic oils, gear oils, light fuel oils and greases) and water-based liquids with a certain working pressure (higher pressure) and humidity (such as emulsified oil, oil and water).
